DETAILS

• Platform

  SuperSix EVO
• Model Name

  SuperSix EVO 4
• Model Code

  C11602U

FRAMESET

• Frame

  SuperSix EVO Carbon, integrated cable routing w/ Switchplate, 12x142 Syntace thru-axle, BSA 68mm threaded BB, flat mount disc, integrated seat binder, SmartSense compatible
• Fork

  SuperSix EVO Carbon, integrated crown race, 12x100mm Syntace thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/4" Delta steerer, 55mm offset (44-54cm), 45mm offset (56-61cm)
• Headset

  Integrated, 1-1/8" - 1-1/4"

DRIVETRAIN

• Rear Derailleur

  Shimano 105 7100, 12-speed
• Front Derailleur

  Shimano 105 7100, braze-on
• Shifters

  Shimano 105 7100, 12-speed
• Chain

  Shimano 105 7100, 12-speed
• Crank

  Shimano 105 7100, 12-speed, 50/34
• Rear Cogs

  Shimano 105 R7100, 11-30, 12-speed
• Bottom Bracket

  Shimano BB-RS500, BSA

BRAKES

• Brakes

  Shimano 105 7170 hydraulic disc, 160/160 RT70 rotors
• Brake Levers

  Shimano 105 7100 hydraulic disc

WHEELS

• Rims

  DT Swiss R460 DB, 28h
• Spokes

  Stainless Steel, 14g
• Tire Size

  25
• Wheel Size

  700
• Hubs

  (F) Formula CL-712, 12x100mm centerlock / (R) Formula RXC-400, 12x142mm centerlock
• Tires

  Vittoria Zaffiro Pro Slick, 700x25c

COMPONENTS

• Handlebar

  Vision Trimax Compact
• Stem

  Cannondale C1 Conceal, Alloy, 31.8, -6°
• Grips

  Cannondale Bar Tape, 3.5mm
• Saddle

  Prologo Nago RS STN, Stainless Steel Rails
• Seatpost

  Cannondale C1 Aero 40 Carbon, 0mm offset (44-48cm), 20mm offset (51-61cm)

CONNECTIVITY

• Wheel Sensor

  Cannondale Wheel Sensor
