DETAILS

• Platform

  Scalpel
• Model Name

  Scalpel 2
• Model Code

  C24303U

FRAMESET

• Frame

  Scalpel, Series 1 Carbon construction, 120mm travel, Proportional Response Suspension and Geometry, FlexPivot Chainstay, full internal cable routing, 73mm BSA, 1.5" headtube with 1-1/8" upper reducer/internal cable guide, 148x12mm thru axle, 55mm chainline, UDH, post-mount disc – 160mm native
• Fork

  RockShox SID Select+ RL, 120mm, DebonAir, 15x110mm thru-axle, tapered steerer, 44mm offset, TwistLoc remote dual lockout
• Headset

  Acros ICR
• Rear Shock

  RockShox SIDLuxe Select+, 2-Pos mode adjust, adjustable rebound, 190x45, TwistLoc remote dual lockout

DRIVETRAIN

• Rear Derailleur

  SRAM GX Eagle AXS, T-Type
• Shifters

  SRAM AXS T-Type Pod Controller
• Chain

  SRAM GX Eagle T-Type, 12-speed
• Crank

  SRAM GX Eagle T-Type, 34T
• Rear Cogs

  SRAM GX Eagle, 10-52, T-Type, 12-speed
• Bottom Bracket

  SRAM DUB BSA 73mm MTB Wide

BRAKES

• Brakes

  SRAM Level Silver Stealth, 4-piston hydraulic disc, SRAM HS2 180/160mm 6-bolt rotors
• Brake Levers

  SRAM Level Silver Stealth

WHEELS

• Rims

  HollowGram XC-S 27, Lightweight, Hi-Impact Carbon, 27mm inner width, 28h, tubeless ready
• Spokes

  Gran Forza, straight-pull
• Tire Size

  2.4
• Wheel Size

  29
• Hubs

  (F) HollowGram, 15x110mm thru-axle / (R) HollowGram w/DT Swiss 350 internals, 12x148mm
• Tires

  (F) Maxxis Rekon Race WT, 29x2.4", EXO Protection, tubeless ready / (R) Maxxis Aspen WT, 29x2.4", EXO Protection, tubeless ready

COMPONENTS

• Handlebar

  Cannondale 1 Flat, Carbon, 31.8mm, 9° back, 760mm
• Stem

  Cannondale C1 Conceal, Alloy, 31.8, -6°
• Grips

  RockShox Smooth Silicone
• Saddle

  Prologo Dimension NDR, STN rails
• Seatpost

  Fox Transfer SL Performance Elite, 31.6, 125mm (S), 150mm (M-XL)

CONNECTIVITY

• Wheel Sensor

  Cannondale Wheel Sensor
