Details

• Platform

  Moterra Neo LT
• Model Name

  Moterra LT 1
• Model Code

  C65134U

Frameset

• Frame

  Moterra LT Carbon, 27.5" rear wheel, 29" front wheel, 165mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH, 200mm native post mount brake, 1.5” – 1.8” tapered headtube
• Fork

  Fox Float Performance 38, 170mm, Grip Damper 3Pos, 15x110mm Kabolt thru-axle, tapered steerer, 44mm offset
• Headset

  Acros ICR, 1.5" to 1.8", sealed bearings
• Rear Shock

  Fox DHX Performance, Coil, 2 pos adj, 230x65mm

E-System

• Drive Unit

  Bosch Performance Line CX
• Battery

  Bosch PowerTube, 800Wh
• Charger

  Bosch 4A
• Display

  Top Tube System Controller w/ Mini Remote

Drivetrain

• Rear Derailleur

  SRAM Eagle 90, T-Type
• Shifters

  SRAM Eagle 90, T-Type, 12-speed
• Chain

  SRAM Eagle 70 T-Type, 12-speed
• Crank

  e*thirteen e*spec Helix Core, 55mm chainline, 160mm, 34T
• Rear Cogs

  SRAM Eagle 70 T-Type, 10-52, 12-speed

Brakes

• Brakes

  TRP EVO Pro 4-piston hydraulic disc, 220/203mm rotors
• Brake Levers

  TRP EVO Pro hydraulic disc

Wheels

• Rims

  DT Swiss H 1900 Spline, 30mm inner width, TC (tubeless ready)
• Spokes

  DT Swiss Competition, straight pull
• Tire Size

  2.5
• Wheel Size

  297
• Hubs

  (F) DT Swiss 370, 15x110mm thru-axle / (R) DT Swiss 370 Ratchet System 18, 12x148mm thru-axle, 6-bolt
• Tires

  (F) Schwalbe Shredda Front, 29x2.5", Radial casing, Addix Ultra Soft Foldable, tubeless ready / (R) Schwalbe Albert, 27.5x2.5", Radial casing, Addix Soft Foldable, tubeless ready
• Front Tire

  Schwalbe Shredda Front, 29x2.5", Radial casing, Addix Ultra Soft Foldable , tubeless ready
• Rear Tire

  Schwalbe Albert, 27.5x2.5", Radial casing, Addix Soft Foldable, tubeless ready

Components

• Handlebar

  Cannondale 3 riser, 6061 Alloy, 25mm rise, 8° sweep, 4° rise, 800mm
• Stem

  Cannondale 1, 6061 Alloy, 35.0, 40mm, 0°
• Grips

  Cannondale TaperRidge
• Saddle

  Fizik Terra Aidon X5, 145mm, Wingflex, S-Alloy Mobius rail
• Seatpost

  Cannondale DownLow Dropper, internal routing, 34.9, 150mm (S), 170mm (M), 200mm (L), 230mm (XL)

Extra

• Extra 1

  Tubeless Valves, Bosch PowerMore range extender compatible
